Three stage, no feedback integrated amplifier. ECC83/6N2P-EW as input stage, EL84/6P14P in single ended configuration as driver and only one pair of HEX-FET transistors per channel in the power stage wich provides 25W to 8 ohm, 45W to 4 ohm and 90W to 2 ohm load. Bias point is set on high current, so a significant part of output power (8W) is provided in pure class A. For greater powers class AB is introduced.
Lack of any negative feedback ensures no TIM distortion and in combination with SE valve driver gives the less audible low-order even THD.
Valve part of the circuit is point-to-point silver wired. Power supply contains EZ81 valve rectifier. Solid state part is built in dual-mono configuration with two separate power supplies.
| Specifications > Amplifier > Haiku Dark |
|---|
| Manufacturer | TALCOMP PRODUCTION |
| Model name | Haiku Dark |
| Kind of amplifier | Integrated amplifier |
| Type | Hybrid |
| Number of channels | 2 |
| Class | A/AB |
| Per channel power output | 50 Watts |
| Input sensitivity | 500 mV |
| Power consumption | 300 Watts |
| Frequency response | from 6 Hz to 180 kHz |
| Number of inputs | 3 |
| Source direct | No |
| Balance | No |
| Treble / Bass | No |
| Loudness | No |
| Source selector | Yes |
| Standby mode | Yes |
| Remote control | No |
| Phono input | No |
| Available front panel colors | Black, Silver |
| Available front panel materials | Aluminium |
| Dimensions (Height/Width/Depth) | 16/37/33 cm |
| Haiku Dark > TALCOMP PRODUCTION |
